Forward Self

Basic Info.

Model NO.	RF655
Mixing Method	Intermittent Compulsory
Automatic Grade	Automatic
Product Capacity	0-5 Km/ H
Certification	ISO9001: 2000, CE
Condition	New
Mark Width	100-500 mm ( Adjustable)
Paint Tank Capacity	55L/ 100kg
Marking Thickness	1.0-4.0mm
Glass Bead Capacity	15 Kg
Engine	Honda 5.5HP Gasoline
Paint Material	Thermoplastic Paint Material
Transport Package	Plywood Box Packing
Specification	1450*1100*1100 mm
Trademark	RoadFly
Origin	China
Production Capacity	760 Sets/Year

Product Description

The Thermoplastic Self-propelled Road Marking Machine is used for marking reflective lines (straight line, dotted lines, direction arrows, letters and symbols) on highway, city street, parking lot, factory and warehouse. It can walk automatically (engine driven).

2.Specifications

3.Features: 4.Our factory
6.FAQ

1.Q:Are you a factory or trading company?

A:We are factory which in this field for more than 10 years.

2.Q:Where is your factory located? How can I visit there?

A:Our factory is located in Linyi City, Shandong Province, China, All our clients, from home or abroad, are warmly welcome to visit us!3.Q:How does your factory do regarding quality control?

A:Quality is priority. All staffs always attach great importance to quality controlling from the very beginning to the very end.Our factory has gained ISO 9001 and SGS authentication.

Contacts: +86-15069968971 Welcome you visit our factory anytime! forward self-propelled thermoplastic road making machine for thermoplastic paint
1.production description

Number code	RF-655
Engine	Honda 5.5 HP petrol engine
Running System	Hydraulic CVT system
Heat method	LPG(liquefied petroleum gas)
Paint barrels	Stainless steel heater and double high-carbon steel bottom, vertical paddle mixer with 75kg or 100 kg capacity
Coadting thickness	1-4 mm(adjustable)
Landing knife	Alloy steel
Glass bead self-synchronization scatter	Self gear shifting seeding.It can adjust glass beads sowing width according to line adjustment.
Glass beads box	10 kg capacity
Operating	Walking speed 0-10km/h; simple construction and high effciency.
Wheel	High temperature resistant soft rubber
Optional Hopper	Engineering requirements in accordance with the replacement of different specifications marking shoes within 10/15/20/30/40/45 cm
Weight	200 kg
Shape dimension	1450*1100*1100mm
